315TPLC controlled automatic vulcanizing machine with automatic push-pull mold device

Main technical parameters of the product:

1. Nominal clamping force ..................................3.15MN
2. Maximum stroke of plunger ................................500mm
3. Hot plate spacing ....................................500mm
4. Hot plate specifications ...................................800*800（mm）
5. Work levels Layer 1
6. Maximum working fluid pressure .............................16Mpa
7. Unit area pressure of hot plate ................................4.9Mpa
8. Total electric motor power ...............................6-4KW
9. Total heating power ..................................19.2KW
10. The maximum working temperature of the hot plate ...........................200℃
11. Cylinder diameter ..................................500mm
12. Number of oil cylinders 1 set/unit
13. Structural form Frame structure
14. Control method PLC control
15. Heating method Electric heating
