Qingdao Yahua Machinery Co., Ltd
3000T vulcanizing machine for producing large rubber sheets, cowshed mats, and pigsty mats
NegotiableUpdate on 03/12
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Technical parameters: Main technical parameters of the product: 1. nominal clamping force................................................. 30
Product Details
Technical Specifications:
Main technical parameters of the product:
1. Nominal clamping force: 30.00MN
2. Maximum pressure of working fluid: 14.7MPa
3. Maximum stroke of plunger: 400mm
4. Hot plate area: 1700 × 3500 (mm)
5. Unit area pressure of hot plate: 2.9MPa
6. Number of working floors: 1 floor
7. Hot plate spacing ............400mm
8. Piston diameter: 600mm
9. Number of plungers 6 sets/unit
10. Heating method: Heat transfer oil heating
11. Structural Form: Frame Plate Structure
12. Control Method: Relay Automatic Control
