Yantai Jinwoquan Plastic Co., Ltd
PE-RT II insulation composite plastic pipe manufacturer
NegotiableUpdate on 04/14
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
PE-RT II insulation composite plastic pipe manufacturer
Product Details
1、 Overview
PE-RT II type prefabricated directly buried thermal insulation composite pipe is closely combined with high-density polyethylene outer protective pipe, polyurethane rigid foam plastic insulation layer and II type heat-resistant polyethylene (PE-RT II) work pipe. Prefabricated direct buried insulation composite pipes are widely used in centralized heating buried secondary heating pipelines, building cold and hot water supply pipeline systems, industrial pipeline systems, etc. due to their excellent performance.
2、 Pipe specifications
The caliber range is dn25mm-dn355mm, and the working pressure can reach 1.0MPa.
3、 Product Features
1. Low heat loss: The operating temperature can reach 80 ℃, and the insulation effect is good (heat loss capacity is less than 0.1 ℃/km).
2. Reliable connection: The pipe adopts electric and hot melt docking, which is convenient and reliable for connection. Compared with the welding method of metal pipes, it reduces the leakage caused by weld corrosion.
3. Corrosion and Wear Resistance: Pipe materials fundamentally solve the corrosion problem of steel pipes, with corrosion and wear resistance far superior to common pipeline materials.
4. Low operating cost: The pipe runs for a long time without scaling, does not affect flow and resistance, and saves transportation costs.
5. Low construction cost: The lightweight weight of the pipes makes construction easier and more economical.
6. Long lifespan: The product has a lifespan of up to 50 years, greatly reducing maintenance and replacement costs.
4、 Application scope
1. Urban centralized heating secondary pipeline network and hot spring water insulation pipeline.
2. Factory air source heat pump hot water project, solar hot water project.
3. Hospitals, hotels, guesthouses, saunas, foot baths, villas, resorts, air source heat pump hot water projects, solar hot water projects.
