Oil circulation injection mold temperature machine

NegotiableUpdate on 04/24

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

The oil circulation injection mold temperature machine plays a significant role in the constant temperature of plastic, extrusion, and composite material molding

Product Details

The oil circulation injection mold temperature machine plays a significant role in the constant temperature of plastic and extrusion, as well as composite material molding. In the molding process, the mold needs to be heated to a certain temperature for constant temperature, and there is also a process of rapid cooling. The machine is equipped with a cooling system device inside, and the mold temperature machine of Kolod Company is customized according to user needs for precision plastic injection, cold feed rubber, pin type extruder, composite tread, tire component production line PC,PP,PET, Temperature control in industries such as nylon 66, polyurethane foam, cable equipment, PVC plastic sheet pipe extrusion equipment, screw plastic extruder, etc.

Introduction to Oil Circulation Injection Mold Warm Machine Products

1. Return oil temperature prediction table

2. Automatic exhaust function upon startup, heating power switching function

3. Negative pressure system operation (selection)

4. Hot oil BY-PASS pressure relief circuit

5. Instant cooling startup function (selection)

6. Multi point temperature control unit can be customized

7. Oil pump horsepower and heating power can be customized

8. The electrical appliances adopt WEST, Qisheng TE、LG 、 Schneider, Siemens

9. Temperature control range: Inlet oil temperature: normal temperature -300 ℃, can also be customized for low-temperature types.

10. Integrated pipeline reduces pipe groups and rust deposits

project	Item	unitUnit	JEWT-20	JEWT-30	JEWT-40
Temperature control range	Temp control range	℃	45℃~300℃Inter water temperature+45℃~300℃
temperature control	Temp control accuracy	℃	PID±1℃
power supply	Power supply		Ac3∮380v (3phase+earth)
Heat transfer media	Heat transfer medium		heat transfer oilThermo conductive oil
cooling method	Cooling method		Indirect coolingIndirect cooling
HEATING CAPACITY	Hearing capacity	KW	18/24	30/36	36/50
Power	Pump power	KW	1.5	2.2	3
Pump working flow rate	Working flow of pump	L/MIN	6	10	12.5
Pump Pressure	Working pressure of pump	KG/CM	2.2	2.8	3
Pressure consumption	Max. power consumption	KW	25.5	38.5	53
function	Alarm function	phase loss/oil starvation/overtemperature/overload/oil spilling/Heating alarm pump reversal/oil shortage/overheating/overload/oil overflow
冷却水配管	Cooling water pipe	INCH	1/2	1/2	1/2
Circulating water piping	Circulating water pipe	INCH	3/4	1	1-1/4
Reference size of the whole machine	Size（LxWxH）	MM	1150x450x1400	1550x500x1450	1770x650x1500

Different maintenance measures should be taken for the oil circulation injection mold temperature machine according to the thermal conductive medium used. For media such as water, using water as a thermal conductive fluid is economical, clean, and easy to use. It is necessary to keep the water source clean or use pure water to raise the temperature, which is not easy to scale and can also prevent pipeline blockage. For media that are oil, we need to regularly check and clean the heating tube according to the usage temperature. If scale is found on the heating tube, fine sandpaper or cotton cloth can be used to remove the oil stains.
