MG-120 series 5-gallon automatic bottle blowing machine

The MG-120 5-gallon automatic blow molding machine and stretch blow molding machine are mainly used for producing 5-gallon PET bottles, which have a high demand in the market. Therefore, the MG-120 has become the preferred investment choice for various PET bottle manufacturers. The production process of MG-120 is computer-controlled, achieving a fully automated level. Generally, during the use of MG-120, the manufacturer connects the blow molding machine with the filling machine through a conveyor belt, so that the produced PET bottles can be directly transported to the filling machine for filling.

control system

The control system is the core of the MG-120 automatic bottle blowing machine. High tech human-machine interactive control panel, lightweight touch screen, accurate control, simple parameter settings, clear numerical display, ideal memory storage capacity.

dynamical system

The power system provides power for the operation of MG-120. It uses world-renowned brand power components, such as FESTO from Germany, to ensure high quality. These high-quality power components have specially made high-pressure valves with high accuracy, long service life, and stable performance. Due to the fact that the manufacturers of these famous brand power components have branches worldwide, customers can easily enjoy after-sales service for related components locally.

sensing system

MG-120 adopts high-quality imported sensing switch system, including proximity switch, photoelectric switch, electromagnetic switch, etc. This ensures the orderly progress of the production process and avoids potential damage to the machines.

Heating system

MG-120 adopts infrared heating mode. Its super strong thermal radiation and penetration ability enable the machine to reach the required temperature during high-speed operation. The infrared lamps are distributed in three heating zones, with corresponding independent voltage adjustment modules and computer control systems, which can provide ideal heating effects for different types of preforms. The horizontal position of each infrared lamp can be adjusted to increase the flexibility of the machine.

clamping system

MG-120 adopts three template clamping device. In addition, there is a specially designed high-voltage auxiliary locking device that provides strong locking force.

Bottle preform transportation and demolding system

The MG-120 fully automatic bottle blowing machine adopts a unique preform feeding system, which ensures that the neck of the preform is not damaged, and can make subtle changes to the preform without replacing the preform tray. The heated preform is blown upwards to ensure the quality of the finished bottle. The formed bottle automatically releases during the operation of the machine.

1. Unique fully automatic feeding system.
2. Suitable for producing wide mouth PET bottles of 5-25L.
3. Advanced PLC control system, lightweight control panel.
4. A sensitive sensing system monitors the automatic operation status of the machine.
5. Advanced heating system, accurate temperature control, and easy adjustment.
6. The cooling system achieves the desired cooling effect.
7. Compact structure, saving installation space.
8. The bottle body is protected from contamination.
9. Special air storage unit.
10. Installation and startup are simple.
11. The scrap rate of finished bottles is less than 0.3%.

oil bottle

Two gallon bucket with handle

20L wide mouthed bottle

Three gallon bucket

Five gallon bucket
