productName: Large Particle Horizontal Blender

meritRate:5.5KW all copper motor with aging wheel reducer

materialQuality: The barrel body is made of 201 stainless steel with a thickness of 4.0mm, and the blade thickness is 14mm

oarYe: 201 stainless steel double S-shaped spiral belt type

RongQuantity: 1000KG

Feeding method: Can be equipped with a spiral feeding machine to reduce the trouble of manual feeding

Mixing time:5-8 minutes

The difference between horizontal mixers and their peers:

1The spindle adopts45 # steel forging, precision grinding, and processing are durable, and the outer shell is made of 201 # stainless steel pipe, which is wear-resistant and has high strength,

Not bent, not deformed, not broken.

2The bearing adopts an external structure and is not directly connected to the barrel, which can effectively prevent materials from entering the mixer barrel

To prevent bearing damage.

3. The blade adopts multi-layer blades, and the design structure is extremely reasonable, ensuring 100% uniform mixing.

4. Personalized production and manufacturing can be carried out according to customer needs

5. All main electrical circuit components are adoptedChintElectrical appliances, safety and humanization.

Product Features:

1. The material bucket and propeller blades are made of stainless steel, which is easy to clean and prevents rusting.

2. Cycloid pinwheel reducer, with long service life and low noise.

3. The protective door is specially designed for easy equipment maintenance and upkeep, and is equipped with a personnel ladder for more convenient feeding.

4. Double directional S-shaped propeller blade, mixing materials quickly and evenly.

5. Top visible window, easy to observe the mixing situation.

6. Timer 0-60 minutes for any timed mixing.

7Can be customized with heating or cooling type.

Product Usage

Suitable for mixing powders and high viscosity materials, widely used in industries such as coatings, putty, mortar, pesticides, plastics, food, etc.

Product advantages:

1The spiral blade flips and pushes the material to mix thoroughly in the container, suitable for high viscosity materials or powders

The mixture.

2. The discharge port adopts a large-diameter pneumatic valve to ensure convenient discharge

3. The blade is made of stainless steel material, mirror polished, easy to clean

4. Complete specifications, processing capacity ranging from 100kg to 15000kg

5Optional explosion-proof, stepless speed regulation, etc.
