Nanjing Kolode Machinery Co., Ltd
Electric heating oil boiler
NegotiableUpdate on 04/24
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Features: Explosion proof device (optional), air blowing and oil return function (optional), oil return temperature display, automatic exhaust function upon startup, heating power switching function, real-time cold on/off function, RS485 communication function
Product Details
feature
Explosion proof device (optional)
Blow back oil function (optional)
Return oil temperature display
Automatic exhaust function upon startup
Heating power switching function
Real time cold on/off function
RS485 communication function for automated management (optional)
Hot oil BY-PASS pressure relief circuit
Multi point temperature control unit can be customized
Oil pump horsepower and heating power can be customized
电器采用 Schneider. WEST. Omron. LS. ABB. SIEMENS. Fuji.
Temperature control range: Inlet oil temperature: Normal temperature -200 ℃
Stainless steel integrated pipeline reduces pipe resistance and rust scale
Control method: Adopting imported microcomputer or (optional) PLC control
Complete safety protection, fault display, repair, and maintenance do not require professional personnel
Model |
Model |
unitUnit |
JOS-05 |
JOS - 10 |
JOS - 20 |
JOS - 30 |
JOS - 50 |
JOS - 75 |
Temperature Control Range |
TempRange |
℃ |
normal temperature-300℃Normal temperature-300℃ |
|||||
Temperature control accuracy |
Temp.Control Accuracy |
PID±1℃ |
||||||
power |
Power Supply |
AC3∮380V 50HZ3P+E（5M） |
||||||
Heat transfer media |
Heat Transfer Medium |
heat transfer oilHeat Conducting Qil |
||||||
Cooling method |
Cooling Method |
Indirect coolingIndirect Cooling |
||||||
Power |
Heating Capacity |
KW |
6/9 |
9/12 |
18 |
24/36 |
48/60 |
75 |
pump power |
Pump Power |
KW |
0.375 |
0.75 |
1.5 |
2.2 |
4.0 |
5.5 |
Pump flow rate |
Pump Folw |
L/MIN |
98 |
150 |
235 |
315 |
367 |
424 |
Pump Pressure |
Pump Pressure |
KG/CM2 |
2 |
2 |
2.3 |
2.6 |
2.8 |
3 |
|
electricity consume |
Power Supply |
KW |
6.5/10 |
10/13.5 |
20 |
27/39 |
52/64 |
81 |
safety function |
Alert Function |
phase loss/oil starvation/over-temperature/overload/ReversePump Reversal/Oil Shortage/Overheating/Overload/reverse turn |
||||||
Cooling water piping |
Cooling Water Pipe |
INCH |
1/2 |
1/2 |
1/2 |
1/2 |
3/4 |
3/4 |
followOil circulation piping |
Circulati Onwater Pipe |
INCH |
1/2 |
1/2*2 |
1/2*2 |
1.2 |
1.5 |
2 |
Overall dimensions |
Size(L*W*H) |
MM |
750*325 *680 |
750*325 *680 |
1000*420 *1000 |
1200*500 *1100 |
1700*550 *1450 |
1700*550 *1450 |
weight |
Weight |
KG |
65 |
90 |
130 |
240 |
290 |
330 |
