KSA120-500L Hollow Blow Molding Machine

Hollow blow molding machine with PLC and human-machine interface, touch based operation. Fault alarm self diagnosis, clear at a glance.
The central feeding type die head completely eliminates the convergence line of products and allows for quick material and color changes.
The mold is moved using double linear guide rails and the center is locked. Uniform force distribution ensures smooth cutting of the product.
The hydraulic system adopts proportional hydraulic control, equipped with imported hydraulic components, with precise, stable and energy-saving actions.
The KSA120-500L hollow blow molding machine adopts a high-speed, efficient, and low-energy plasticizing system, which ensures excellent mixing and ensures product purity.
Large blow molding machine

KSA120-500L Hollow Blow Molding MachineTechnical Specifications	UNIT	KSA120-500
Maximum product volume	L	500
empty loop	PCS/H	200
screw diameter	MM	120
Blow molding machine screw length to diameter ratio	L/D	30
Screw motor power	KW	110
Screw heating power	KW	39
Number of screw heating sections	ZONE	6
HDPE extrusion volume	KG/H	380
Oil pump motor power	KW	45
clamping force	KN	1500
Opening and closing stroke of the mold	MM	600-1500
Template size	W x H(MM)	1450x 1800
Maximum die diameter of hollow blow molding machine	MM	600
Storage capacity	L	30
Heating power of mold head	KW	39
Number of heating sections	ZONE	6
blowing pressure	MPA	1
Gas consumption of blow molding machine	M3/MIN	1.8
cooling water pressure	MPA	0.3
water consumption	L/MIN	250
Machine dimensions	L x W x H(M)	9.1x 4.2x 6.3
machine weight	TON	40
