Heavy duty PET strapping production line

Product Description:

The PET strapping produced by the heavy-duty PET strapping production line, also known as plastic steel strip, is a new environmentally friendly packaging material used to replace steel strip in the world. After the successful development of new materials and significant cost reduction in recent years, it has been widely used in the steel industry, chemical fiber industry, aluminum ingot industry, paper industry, brick kiln industry, screw industry, tobacco industry, electronics industry, textile industry, and wood industry; It is a new type of high-strength strapping that replaces steel strips and is currently the most widely used alternative steel strip product in the world.

Equipment features:

PET and PP share the same production line technology, and the production setup can be completed within a few minutes; The PET strapping production line can produce four out, six out, and eight out.

1. Raw material processing and extrusion system

1.1. Efficient pre crystallization and drying system;

1.2. The equipment can use 100% bottle recycling materials to produce high value-added packaging belts;

1.3. Specially designed PET special screws, single and double screw extruders are available for selection.

2. Continuous backwash filter screen changer (European technology)

2.1. 100% automatic flushing filter screen, with 4 filter chambers in double columns;

2.2. PLC control, non-stop network replacement, does not affect product quality.

3. Specially designed hot oven

3.1. Configure heating units, automatic temperature control systems, and high-performance insulation layers;

3.2. Better achieve the stretching and heating of the strip, quickly raise the temperature, and complete the stretching of the strip.

4. Embossing machine

4.1. Hydraulic control, can set the pattern of the embossing roller according to user requirements;

4.2. Equipped with a synchronous control embossing system, it accurately adjusts the up and down position of the embossing roller and the embossing strength.

5. Packaging belt heat setting device

5.1. Special setting technology ensures rapid shaping of tape products and prevents PET tape from unraveling after removal;

5.2. Remove internal stress to ensure the dimensional accuracy and quality of the strap.

6. The characteristic part of this packing belt production line is the storage belt device

6.1. The storage tape length can be controlled according to the winding speed, and the winding tension can also be controlled;

6.2. Thoroughly cool the packaging tape twice to reduce the sickle bending caused by tape winding.

7. Single station and dual stationServo winding machineOptional

7.1. PLC operation control, automatic adjustment of winding tension to meet the winding of 5-32mm belts;

7.2. Servo control of the width and distance of the ribbon cable greatly reduces the bending of the ribbon, ensuring that the ribbon is suitable for automatic packaging equipment.

ERMER Packaging Belt Production Line Equipment from Italy
