Flexible graphite disk root ring seal

Flexible graphite disk root ring sealApplication media include hot water, high temperature, high pressure, steam, media, ammonia, hydrogen, organic solvents, low-temperature liquids, etc. Technical parameters: pressure ≤ 25MPa, temperature -240-3000 ℃, exchange mesons 2-15m/s, pH value 0-14, density 1.7-2.1g/cm3

Flexible graphite disk root ring sealUsed in industries such as petroleum equipment, power plants, chemical engineering, steel mills, etc.

Performance characteristics: corrosion-resistant, suitable for high temperature and high pressure parts. Universal rooting for application devices.
Sex graphite packing ring, made of graphite packing or various reinforced graphite packing such as fiberglass reinforced graphite packing, stainless steel wire reinforced graphite packing, nickel wire reinforced graphite packing INCONEL wire reinforced graphite packing, molded into a ring by mold, can be used for sealing the upper and lower end faces of the packing box, or can be used separately as a set. It combines
The advantages of packing and ordinary graphite rings are particularly suitable for sealing in high-temperature and high-pressure areas.

Flexible graphite tape or flexible graphite is used to weave fillers, which are molded into circular products of different sizes.

Suitable for media such as hot water, high temperature, high pressure steam, heat exchange liquids, nitrogen, organic solvents, hydrocarbons, low-temperature liquids, etc.

Used for compressors, pumps, valves, chemical instruments, meters, etc. Different from flexible graphite packing main!

andFlexible Graphite Packingdifferences

Flexible graphite packing is mainly made of various reinforced fibers, metal wires (steel wire, copper wire, nickel wire, carbon fiber, pre oxidized wire, glass yarn) and other reinforced graphite wires woven with precision as raw materials. Suitable for dynamic sealing under high temperature and high pressure conditions. Except for a few strong oxidants, it can be used to seal media such as hot water, superheated steam, heat transfer fluids, ammonia solutions, hydrocarbons, and low-temperature liquids. It is mainly used for sealing valves, pumps, and reaction vessels in high-temperature, high-pressure, and corrosion-resistant media. It is also a unique universal sealing gasket
