CM-A1 Fully Automatic Bottle Blowing Machine
NegotiableUpdate on 01/18
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
CM-A1 fully automatic bottle blowing machine features: The CM-A1 fully automatic bottle blowing machine is suitable for blowing any shape of plastic containers and bottles made of PET as raw material, and is widely used for blowing carbonated beverage bottles, mineral water bottles, oil bottles, pesticide bottles, and cosmetic bottles
Product Details
characteristic:
The CM-A1 fully automatic bottle blowing machine is suitable for blowing any shape of plastic containers and bottles made of PET as raw material. It is widely used for blowing carbonated beverage bottles, mineral water bottles, oil bottles, pesticide bottles, and cosmetic bottles.*Reasonable design, fully automatic control, operation using fully computerized digital control, small spacing between preforms,
Uniform heating greatly reduces power consumption and manpower.
*Automatic feeding system for pipe blanks.
*The production process is fully automated.
Main parameters:
| model | project | CM-A1(2L) | CM-A1(5L) |
| production | According to the bottle shape | 800-1200 bottles/hour | 500-800 bottles/hour |
| Bottle making specifications | volume | 0.1-2L | 2-5L |
| Bottle diameter | ≤100mm | ≤175mm | |
| Bottle height | ≤330mm | ≤330mm | |
| Bottle mouth diameter | ≤30mm | ≤45mm | |
| mold | No. of Cavities | 1 | 1 |
| mold thickness | 240mm | 260mm | |
| Effective area of mold | 300*240*380 | 300*260*380 | |
| power | supply voltage | 380V/220V 50/60HZ 3-phase | 380V/220V 50/60HZ 3-phase |
| Installed power | 25kw | 25kw | |
| Power usage | 7kw | 10kw | |
| Gas source | Blowing bottle pressure | 1.6m3/min 3.0Mpa | 1.6m3/min 3.0Mpa |
| Bottle transport pressure | / | 1.0m3/min 1.0Mpa | |
| air receiver | / | 0.6m3/min 3.0Mpa | |
| Air Dryer | 1.0m3/min 3.0Mpa | 2.0m3/min 3.0Mpa | |
| cooling water | Water cooler | 3HP | 3HP |
| host | Dimensions (length * width * height) | 1500*1200*1800mm | 2000*1200*1800mm |
| weight | 1500kg | 1800kg | |
| loading machine | Dimensions (length * width * height) | 2000*950*2480mm | 2000*950*2480mm |
| weight | 250kg | 250kg |
