ZYTP series synchronous self-priming pump

I. Overview
The ZYTP series single-stage single suction horizontal synchronous self-priming pump is the best product to replace submersible pumps. Using the latest and excellent hydraulic models, designed and manufactured according to ISO2858 international standards, it can transport various liquids without solid particles.
2、 Purpose:
Industrial and urban water supply and drainage, high-rise building pressurized water supply, garden sprinkler irrigation, fire pressure boosting, air conditioning, heating, cooling and freezing systems, boiler high-temperature hot water and other pressurized and supplied water.
Transporting water, chemical media, and various liquids in industries such as food, medicine, chemical, and petroleum.
3、 Usage conditions
Maximum working pressure: ≤ 1.6MPa (suction pressure+pump head<1.6MPa)
Medium temperature: -10 ℃~80 ℃, 120 ℃, ambient temperature<40 ℃, relative humidity<95%.
The volume content of solid particles in the conveying medium shall not exceed 0.1% of the unit volume, and the particle size shall be less than 0.2mm.
4、 Structural characteristics
The pump has a horizontal structure, with an inlet that can be oriented in any direction and an outlet that is vertically upward.
Less components, compact structure, smooth operation, low vibration, and low noise.
Small footprint, easy installation, and no need to move pipelines for maintenance.
The shaft seal adopts mechanical sealing, with no leakage design and long service life.

The series and parallel operation of pumps can be adopted according to the needs of flow rate and head.
