Medical three-layer (two-layer) light shielded infusion tube production line

The recommended usage characteristics for this series of equipment are dual machine co extrusion structure, three-layer or two-layer co extrusion special mold, vacuum sizing cooling water tank, servo traction cutting machine, belt conveyor, etc. Users can choose an online tracking outer diameter measuring instrument. With efficient and sufficient plasticization, precise control of molds and flow rates, the pipeline can be well bonded without delamination, reducing the migration of light shielding layers; The replacement of the dedicated mold can be applied to the double-layer co extrusion flat mouth drip hopper of OD20, with an inner layer thickness of about 0.2~0.25 and an outer layer thickness of 0.65~0.7mm. The mold structure is non adjustable, with uniform distribution of the inner and outer layers, no dead corners in the mold flow channel, and quick and convenient mold removal, improving production efficiency.

Applicable pipe diameter range: OD1.5~OD20mm

Applicable materials: medical grade PVC material, PVC opaque material, TPU, TPE material, etc.
