Overview
LFQ-A vertical automatic slitting machine
Product Details
This machine is suitable for slitting various roll shaped materials such as BOPP, PET, CPP, CPE, PVC, PE, aluminum foil, paper, etc., and for cutting edges and slitting materials according to different needs during the production process
Product threading diagram:
Main technical parameters
| model | LFQ-700A | LFQ-1100A | LFQ-1300A |
| Width of slitting coil material | 700mm | 1100mm | 1300mm |
| Cut coil diameter | Φ600mm | Φ600mm | Φ600mm |
| Width of slitting coil material | 30-600mm | 30-600mm | 30-600mm |
| Slitting Speed | 5-160m/min | 5-160m/min | 5-160m/min |
| Correction error | <±0.5mm | <±0.5mm | <±0.5mm |
| total power | 2.7kw | 3.5kw | 3.5kw |
| Whole machine weight | 1200kg | 1500kg | 1800kg |
| External dimensions | 2000×1110×1400mm | 2400×1110×1400mm | 2600×1110×1400mm |
