Continuous mixer (double rotor mixer)

Continuous mixing machine (double rotor mixing machine) 1. Working principle: The most obvious feature of a continuous mixing machine is continuous feeding. Its productivity provides feeding speed to ensure constant feeding, which can increase the rotor speed and obtain greater shear force, or slightly close the discharge door to increase the discharge angle temperature. The mixing machine operates at normal pressure, forming an independent mixing environment that is completely unaffected by forming requirements

1、 Working principle:

The most obvious feature of a continuous mixing machine is continuous feeding. Its productivity provides a constant feeding speed, which can increase the rotor speed, obtain greater shear force, or slightly close the discharge door to increase the discharge angle temperature. The mixing machine operates at normal pressure, forming an independent mixing environment that is completely unaffected by forming requirements.

2、 Suitable materials for continuous mixer:

1. Carbon black masterbatch

2. Calcium powder filled masterbatch

3. Talc powder filled masterbatch

4. Functional masterbatch

5. High concentration color masterbatch

6. Flame retardant masterbatch

7. Cable material

8. High filling materials, etc

9. Modified material

10. Thermoplastic elasticity

3、 Unit characteristics:

1. High degree of automation and high production efficiency;

2. Continuous production, stable formula, and excellent product quality;

3. The environment of the masterbatch production workshop is clean and tidy;

4. The self-cleaning ability inside the barrel and on the screw is strong, and it is very convenient to clean the barrel and screw when changing the rubber material, which is suitable for mixing multiple types of rubber materials;

5. The continuous mixer has no dust flying, while the pressurized chamber mixer has dust flying, which can cause significant harm to the operator's body;

6. Factory building: Continuous internal mixing granulation unit, small footprint, low floor requirements;

7. Automation: The combination of machine automation reduces manual operations and improves production efficiency;

8. Quality: Continuous mixing unit, continuous operation, and good stability of discharge quality;

9. Continuous mixing unit, there is no obvious peak current during the mixing process, the current is stable and steady, and the motor energy saving is significant;

10. Excellent mixing and blending effect, with better dispersion effect;

11. To achieve maximum automatic control and generation, it is necessary to cooperate with mixers, weight loss weighing and measuring equipment.
