Computer controlled high-speed continuous roll vest bag making machine (double-layer)

NegotiableUpdate on 03/20

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

Purpose: This machine is specially designed as a flat pocket with a point break connection for rolling

Product Details

Purpose:

This machine is specially designed as a flat pocket with a point break connection. By using computer control and a stepper (servo) fixed length system, the sealing and cutting size errors are minimized. The electronic eye tracking device ensures precise positioning of the printed bag pattern. You can choose computer numerical control to adjust the length of the bag. If there is a problem with the printing bag, the machine will automatically shut down and sound an alarm.

The high-density and low-density polyethylene film bags produced by this machine are suitable for supermarket shopping and mall shopping.

Main technical parameters:

model	600	800	1000
Maximum width mm	500	700	900
Sealing and cutting length mm	1000	1200	1200
Speed g/min	30-120	30-120	30-120
Motor power kw	1.1	1.5	1.5
Machine weight kg	800	900	1000
Dimensions mm (L×W×H)	3600x1200x1650	3600x1300x1700	3600x1500x1700
